YAMAHA YRM-520 FM VOICING PROGRAMII OWNER'S MANUAL

About this manual

The Yamaha YRM-502 is a ROM cartridge designed to expand the capabilities of the Yamaha FM Sound Synthesizer unit (SFG-01 or SFG-05). It allows users to alter existing voices and create new ones from scratch using the FM sound generation system. The program supports data display on an MSX computer screen, audio output for checking voice data during editing, and saving created data to cassette tapes, Data Memory Cartridges (UDC-01), or floppy disks.

What's inside

• System Components
• System Connections
• Initial Displays and Program Outline
• Displaying the Screen Pages
• Keyboard Operation
• Commands
• File Mode
• Edit Mode
• Creating Voices
• FM Voice Synthesis Theory

Frequently asked questions

What is the Yamaha FM Voicing Program II used for?

It is a ROM cartridge used with the Yamaha FM Sound Synthesizer unit to create and alter voices.

What additional voices does this program provide beyond the synthesizer's built-in options?

The program allows for the creation of a wide variety of original voices in addition to the 46 voices already contained in the FM Sound Synthesizer unit.

What are the requirements for saving newly created voice data to a floppy disk?

Saving voice data to a floppy disk is only possible when using the SFG-05 or SFK-05 Synthesizer unit.
