The TC1413/TC1413N are 3A CMOS buffer/drivers with a wide operating range of 4.5V to 16V and can withstand up to 5V of negative input. They also have a short delay time of 35nsec.
The TC1413/TC1413N are 3A CMOS buffer/drivers designed to drive high capacitive loads, such as MOSFET gates. They feature matched rise and fall times, low output impedance, and robust protection against latch-up and electrostatic discharge (ESD). The device is available in both Inverting (TC1413) and Noninverting (TC1413N) configurations.
| Peak Output Current | 3A |
|---|---|
| Capacitive Load Drive Capability | 1800pF in 20nsec |
| Operating Voltage Range | 4.5V to 16V |
| Short Delay Time (Typical) | 35nsec |
| ESD Protection Level | 4kV |
| Output Resistance (Typical) | 2.7Ω |
The device operates with a supply voltage range of 4.5V to 16V.
Yes, the inputs can withstand negative voltages up to 5V without damage.
The typical short delay time is 35 nanoseconds.
