FBR18 SERIES MINIATURE RELAY (SURFACE MOUNT TYPE) 2 POLES—1 to 2 A (FOR SIGNAL SWITCHING)
This document provides technical specifications for the Fujitsu Components FBR18 series of miniature surface mount relays. These 2-pole relays are designed for signal switching with a current rating of 1 to 2 A. The series features a super miniature size of 0.2 inch x 0.1 inch grid and is available in N and W types with various nominal coil voltages ranging from 3VDC to 24VDC.
| Contact Arrangement | 2 form C (DPDT) |
|---|---|
| Maximum Carrying Current | 2 A (at 20°C) |
| Maximum Switching Power | 62.5 VA or 60 W |
| Operating Temperature | -40°C to +85°C |
| Weight | Approximately 1.9 g |
The contact arrangement is 2 form C (DPDT).
The maximum carrying current is 2 A at 20°C.
One reel contains 500 pieces.
