The YST-MSW10 Active Servo Technology is an active servo processing subwoofer system. It features powerful and adjustable power, high cut, and volume for both high and low frequencies.
The Yamaha YST-MSW10 is an active servo processing subwoofer system featuring a 6.3-inch cone woofer with magnetic shielding. It includes built-in power amplification and offers selectable high-cut filter frequencies (Low or High) to optimize audio performance for various speaker systems.
| Amplifier output | 25 W/4 Q (THD 10%, 100 Hz) |
|---|---|
| Pressure Level | 98 dB (max.) |
| Capacity | 8.02 |
| Frequency response | 35 to 250 Hz (-10dB) |
| Power supply | AC 120 V, 60 Hz |
| Power consumption | 25 W |
| Dimensions (W x H x D) | 280 (11") x 200 (7.9") x 248.5 (9.8") mm |
| Weight | 5.5 kg (12.1 Ibs) |
The HIGH CUT switch allows you to select either LOW or HIGH frequency settings.
If no input signal is received after 5-10 minutes, the power switches off automatically and turns back on when a signal is detected.
The package includes one mini plug cable, one RCA pin to Mini plug adaptor, and one 1/4" Phone to Mini plug adaptor.
