This document is the operating manual for the Yamaha PM-3000 mixing console. It provides brief operating instructions for engineers and technicians familiar with sound system design, as well as background information for better utilization of the console and auxiliary equipment.
The manual details the front and rear panel features, including input modules, master modules, and power supply specifications. It covers essential topics such as installation notes regarding grounding and AC mains, gain structure concepts, optional functions like VCA calibration, and maintenance procedures.
| Document Type | Operating Manual |
|---|
Do not expose the appliance to rain or moisture to prevent fire or shock hazard.
There are eight groups, which may also be referred to as subgroups.
The Group Master Faders control the level on the eight Group Mixing Busses.
