Yamaha CBX-D5 Digital Recording Processor System Setup Guide

About this manual

This document serves as a system setup guide for the Yamaha CBX-D5 Digital Recording Processor. It provides specific instructions for connecting the device to three different computer configurations: Cubase Audio on Atari ST/STE, Cubase Audio on Atari TT, and Digital Performer on Apple Macintosh.

The guide details the required hardware components, such as SCSI cables, MIDI cables, and power supplies, and outlines step-by-step connection procedures. It also covers essential configuration settings for SCSI IDs and switch positions to ensure proper communication between the processor and the host computer.

What's inside

• Introduction
• Cubase Audio & Atari ST/STE System
• Cubase Audio & Atari TT System
• Digital Performer & Apple Macintosh System

Frequently asked questions

What computer and software are required for the Atari ST/STE system?

The system requires an Atari ST computer running Steinberg's Cubase Audio software.

What SCSI ID must be set on the CBX-D5 for the Atari TT system?

The CBX-D5 must be set to SCSI ID 5 or 6 using the thumb wheel switch.

What is the recommended storage configuration for the Atari TT system?

The internal hard disk should store software and data, while an external hard disk must be used for recording sound files.
