This document provides the installation guide for the Agilent 7683 Automatic Liquid Sampler, including information on the equipment's safety features and precautions.
This document provides instructions for installing the Agilent 7683 Automatic Liquid Sampler. It details the assembly of components including the G2612A ALS Interface Board (if purchased), the optional G2614A Tray, and the G2613A Injector module onto a 6890 GC system.
The guide covers specific installation steps for the tray quadrants, injector mounting post replacement, and cable connections. It also includes procedures for configuring the Gas Chromatograph (GC) and performing a trial run to verify proper operation. This manual is written in Japanese.
| Safety Class | Class 1 |
|---|---|
| Pollution Degree | 2 |
| Fuse F001/F002 Rating | 3 A, 250 VAC |
| Fuse F201/F202 Rating | 10 A, 250 VAC |
| Fuse F101 Rating | 0.5 A, 250 VAC |
Check that the cable connection to the GC is secure, or contact Agilent service if the board has failed.
Fuses F001 and F002 are rated at 3 A, 250 VAC.
The lithium battery has a capacity of 1.200 mAh.
