Agilent Technologies 19239A/B Cryogenic Oven Cooling Installation Guide

About this manual

This document serves as an installation guide for the Agilent Technologies 19239A (Cryogenic Oven Cooling, CO) and 19239B (Cryogenic Oven Cooling, Ny) accessories. It details the preparation of a Gas Chromatograph (GC) prior to installation.

What's inside

• Safety Information
• Preparing the GC
• Installing the Cryogenic Valve
• Connecting Leads

Frequently asked questions

What safety equipment is required when installing the cryogenic valve?

You must wear long sleeves, gloves, safety glasses, and a disposable dust/mist respirator.

How many screws secure the autosampler bracket to the instrument?

The autosampler bracket is secured by six screws.

What size nut and washer are used to secure the cryo valve assembly?

Use a flat washer and an M4 nut on each of the three mounting studs.
