This document provides specifications and characteristics of E-Switch R6 series switches, including rated current, mechanical life, electrical life, contact resistance, insulation resistance, dielectric strength, etc. The switch features a body and rocker made of nylon 66, a contact surface of coin silver, and a terminal of silver plated copper alloy. It is safety standard approved by UL, CSA, VDE, Semko, Nemko, Demko, Fimko. The switch can be customized with different options such as housing color, actuator color, and termination.
The E-SWITCH R6 series offers rocker switches rated at 10A@125VAC or 6A@250VAC with UL, CSA, VDE, and other safety approvals. Switches feature nylon 66 bodies, coin silver rockers, and silver-plated copper alloy contacts. Options include SPST and SPST (On)-Off configurations with color-coded housings and terminations.
Ordering includes circuit code, housing color, actuator color, marking, and termination type. Panel mounting options are available with specified cut-out dimensions and terminal thicknesses for quick-connect connectors.
| Rating | 10A@125 VAC, 6A@250 VAC |
|---|
SPST On-Off (A) and SPST (On)-Off (B).
10A at 125 VAC.
Less than 20 mΩ (initial).
