The AD9060 is a 10-bit/75 MSPS monolithic converter capable of word rates of 75 MSPS and above. Innovative architecture using 512 input comparators instead of the traditional 1024 required by other flash converters reduces input capacitance and improves linearity. Inputs and outputs are ECL-compatible, which makes the AD9060 the recommended device for these applications.
The AD9060 is a monolithic 10-bit analog-to-digital converter capable of word rates up to 75 MSPS. It utilizes an innovative architecture with 512 input comparators to reduce input capacitance and improve linearity compared to traditional flash converters requiring 1024 comparators.
The device features ECL-compatible inputs and outputs, making it suitable for high-speed systems exceeding 30 MSPS to minimize system noise. It includes an overflow bit to indicate analog input signals greater than +V SENSE and voltage sense lines to ensure accurate driving of the ±VREF voltages.
| Resolution | 10 Bits |
|---|---|
| Conversion Rate | 75 MSPS |
| Analog Bandwidth | 175 MHz |
| Operating Temperature (Commercial) | 0 °C to +70 °C |
The device supports word rates of 75 MSPS and above.
It uses 512 input comparators instead of the traditional 1024 required by other flash converters.
The converter has a resolution of 10 bits.
