The AME8806/8809/8842 is a family of positive, linear regulators with low quiescent current and low dropout voltage, making them ideal for battery applications. It features thermal shutdown and current fold-back for protection under extreme operating conditions. It is suitable for instrumentation, portable electronics, wireless devices, and more.
This document describes the AME8806/8809/8842 family of positive linear regulators from Analog Microelectronics. These devices feature a guaranteed 600mA output current, very low quiescent current (30µA typical), and low dropout voltage, making them suitable for battery-powered applications such as portable electronics and wireless devices.
The datasheet provides detailed electrical specifications, including input/output voltage ranges, temperature coefficients, and noise performance. It also covers ordering information for various output voltages and the SO-8 package, along with recommended operating conditions and absolute maximum ratings.
| Output Current | 600 mA |
|---|---|
| Quiescent Current | 30 µA typ. |
| Output Voltage Accuracy | 1.5% |
| Operating Temperature Range | -40°C to +85°C |
| Package Type | SO-8 |
| Thermal Shutdown Threshold | 150°C |
The typical quiescent current is 30µA.
Yes, it is stable with an output capacitance of 2.2µF or greater.
