This manual introduces the functions and usage of Agilent Cary 630 FTIR spectrometer
The Agilent Cary 630 FTIR is a compact mid-infrared spectrometer designed to provide traditional analytical capabilities without high complexity or cost. It utilizes Fourier transform infrared (FTIR) spectroscopy with a unique Michelson interferometer design, featuring a low-powered solid-state laser and a thermoelectrically-cooled dTGS detector.
The guide details the complete user workflow, including unpacking, installation of power and computer connections, and turning the instrument on or off. It provides specific instructions for analyzing samples using five different sampling accessories: Diamond ATR, Transmission, TumblIR, DialPath, and Diffuse Reflectance. Additionally, it outlines maintenance tasks such as cleaning, replacing desiccant, windows, and the source.
| Maximum spectral resolution | 2 cm-1 |
|---|---|
| Detector type | thermoelectrically-cooled dTGS |
| Power supply | 100–240 V AC, 3 A, 50–60 Hz |
| Operating temperature range | 0–40 °C; -32–104 °F |
| Storage temperature range | -30–60 °C; -22–140 °F |
The system supports Diamond ATR, Transmission, TumblIR, DialPath, and Diffuse Reflectance sampling accessories.
No, the system is not intrinsically safe and should only be used in atmospheres tested for flammable materials.
The system is computer-controlled using Agilent MicroLab PC software.
