The document serves as an instruction manual for the Actron Model 2510 Transmission/Engine Oil Pressure Kit. It outlines critical safety guidelines regarding eye protection, fire hazards, hose handling, and vehicle ventilation before conducting tests.
The guide details procedures for testing transmission or engine oil pressure in three scenarios: while driving, on a dynamometer test stand, and statically. It includes specific steps for selecting the correct gauge (80 psi or 400 psi), attaching adapters to vehicle test ports, checking for leaks, reading pressure values, and properly disconnecting equipment.
Always start with the 400 psi gauge.
Turn off the engine immediately and allow it to cool before disconnecting.
No, do not repair a damaged hose or fitting; replace the entire assembly.
