Linear Technology LTM4613 Ultralow-EMI Step-Down uModule Regulator Data Sheet

This article introduces the LTM®4613 8A µModule® step-down regulator, which is available in a 15mm x 15mm ultra-compact package and provides up to 96W of output power. The regulator meets EN55022 Class B standards by combining high performance with ultra-low EMI.

Brand: Linear Technology
Category: Power Management
Document type: Product Leaflet
Language: English
Pages: 3
File format: PDF
File size: 2 MB
Published: 05 June, 2012
Updated: 01 October, 2023
MD5 checksum: AC7A12ED5B090F5F6ACC3CF07E71ACFF
PDF: Linear Technology LTM4613 Ultralow-EMI Step-Down uModule Regulator Data Sheet PDF

About this manual

The document introduces the LTM4613, a step-down regulator designed to address Electromagnetic Interference (EMI) challenges in information technology and communications systems. It highlights the difficulty of meeting international EMI standards like FCC Part 15 Subpart B and EN55022 as power budgets increase.

What's inside

EMI Radiation Sources
Parasitic Impedances
EMI Mitigation
Guaranteed EMI Compliance
Application Circuit

Frequently asked questions

What is the maximum output power rating of the LTM4613?

The regulator provides up to 96W of output power.

What is the maximum total DC error over line, load, and temperature?

The regulator maintains a 2.0% maximum total DC error.

Download PDF (2 MB)
