This document provides technical specifications for the Macintosh Performa 5300CD series computers, including the processor, memory, disk drives, and video screen.
This document provides technical information for the Apple Performa 5300 series computers. It details the main unit specifications, including the PowerPC 603e processor running at 120 MHz and dynamic random-access memory capabilities up to 64 MB.
The guide also outlines video screen capabilities with a 15-inch CRT, CD-ROM drive performance metrics, supported sound modes, and various interface ports such as ADB, serial, and SCSI.
| Processor | PowerPC™ 603e processor at 120 megahertz (MHz) clock frequency |
|---|---|
| Memory Minimum | 8 MB |
| Maximum Memory | 64 MB |
| Screen Size | 15-inch CRT |
| Video Resolution | 832-by-624 resolution with 8-bit color |
| Power Consumption | 125 watts |
The system uses a PowerPC 603e processor running at 120 megahertz.
A minimum of 8 MB of DRAM is installed, with a maximum expansion to 64 MB.
The unit operates within a temperature range of 10° C to 40° C.
