This document describes how to use the Component AV Cable to connect your iPod, iPhone, or iPad to the component video and analog audio ports on your TV, home theater receiver, or stereo receiver.
The Component AV Cable lets you link an iPod, iPhone, or iPad to the component video (Y, Pb, Pr) and analog audio inputs of a TV, home‑theater receiver, or stereo receiver. The cable includes a USB connector for power, so the device stays charged while in use.
Before connecting, lower the device volume, turn off all components, and ensure all plugs are firmly seated. The guide provides step‑by‑step instructions, safety warnings, and multilingual notes (English, French, German, Spanish, etc.). It also includes European compliance and disposal information.
| Video connectors | Red, green, blue component video (Y, Pb, Pr) |
|---|---|
| Audio connectors | White (left) and red (right) analog audio |
| Power connector | USB A connector for power (USB Power Adapter or computer) |
Connect the red, green, and blue video plugs to the component video inputs (Y, Pb, Pr) and the white and red audio plugs to the left and right analog audio inputs, then attach the iPod Dock connector to your device and the USB connector to a power source.
Yes, the cable can still be used for audio output, data syncing, and charging even if video is not supported.
The cable’s USB connector should be plugged into a USB Power Adapter or a computer to supply power and keep the device charged.
