The Composite AV Cable is used to connect your iPod, iPhone, or iPad to the composite video port and analog audio ports on your TV, home theater receiver, or stereo receiver. It has a USB connector for power source.
This guide provides step‑by‑step instructions for using the Composite AV Cable with iPod, iPhone, or iPad devices. It covers safety precautions, proper connector placement, and how to power the cable via USB.
The manual also includes multilingual notes (English, French, German, Spanish, Portuguese, Korean, Turkish) and disposal/recycling information required by regulatory authorities.
| Video connector color | Yellow |
|---|---|
| Audio connector colors | White (left) and Red (right) |
| USB connector purpose | Power source for charging |
| iPod Dock connector type | Dock connector |
Plug the yellow video connector into the video input port, the white and red audio connectors into the left and right audio inputs, and the iPod Dock connector into your device.
Yes, you can use the Composite AV Cable for syncing content and charging even if your iPod lacks video output.
Turn off the power to all components before making any connections.
