Featured Composite manuals
Apple Composite AV Cable User Manual
This manual describes the Composite AV Cable, which lets you link an iPod, iPhone, or iPad to the composite video and analog audio inputs of a TV, home theater, or stereo receiver. It details the required connections: yellow video, red and white audio, the iPod dock connector, and a USB power source.
Safety and setup notes include turning off all equipment before connecting, ensuring connectors fit without force, and configuring the iOS device to output video. The cable can also be used for syncing and charging when video output is not supported.
Covers: Important · Connecting the Cable · Powering the Cable · Device Setup
Latest Composite manuals
Composite AV Cable User Guide
The Composite AV Cable is used to connect your iPod, iPhone, or iPad to the composite video port and analog audio ports on your TV, home theater receiver, or stereo receiver. It has a USB connector for power source.
Apple Composite AV Cable User Manual
User Manual 16 pages · 1.1 MB · ENThe Apple Composite AV Cable User Manual explains how to connect your iPod, iPhone, or iPad to a TV or receiver using composite video and audio connectors…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Composite manuals
How do I connect the Composite AV Cable to my TV or receiver?
Plug the yellow video connector into the TV’s video input, the white and red audio connectors into the left and right audio inputs, attach the iPod dock connector to your device, and connect the USB plug to a computer or USB power adapter.
Do I need to set my iPod, iPhone, or iPad to output video?
Yes, set your iPod, iPhone, or iPad to send a video signal before using the cable; see the Apple device user guide for instructions.
