TX6 ™ PLUS patch cords are constructed of 24 AWG unshielded twisted pair stranded copper cable and meet TIA/EIA-568-B.2-1, ISO 11801 2nd Edition Class E standard requirements. These patch cords support both T568A and T568B wiring schemes to ensure compatibility with connecting devices
The TX6 PLUS Patch Cords are Category 6/Class E unshielded twisted‑pair cables with enhanced RJ45 plugs, designed for both T568A and T568B wiring schemes and certified to meet TIA/EIA‑568‑B.2‑1, ISO 11801, FCC Part 68, IEC 60603‑7 and UL 1863 standards.
They feature 24 AWG stranded copper conductors, 50 µin gold‑plated contacts, a slender strain‑relief boot, an integral pair manager, and a patented tangle‑free latch. The cords are offered in a range of colors and lengths from 3 ft to 20 ft.
| Category | Category 6/Class E |
|---|---|
| Frequency Range | up to 250 MHz |
| FCC Compliance | Meets FCC Part 68 Subpart F |
| IEC Compliance | Meets IEC 60603‑7 |
| UL Rating | No. 1863 |
| Conductor Size | 24 AWG stranded copper |
| Contact Plating | 50 µin gold |
| Available Lengths | 3, 5, 7, 10, 14, 20 ft |
It meets TIA/EIA‑568‑B.2‑1 Category 6 and ISO 11801 Class E standards, and complies with FCC Part 68, IEC 60603‑7 and UL 1863.
The RJ45 contacts are plated with 50 microinches of gold.
Lengths are available in 3 ft, 5 ft, 7 ft, 10 ft, 14 ft and 20 ft.
