The BDS830FS is a monolithic integrated circuit audio sound processor for TV and other audio‑visual equipment. It includes features such as a low‑sound equalizer (P‑Bass), built‑in Shadow Bass Sound, BBE processing, TruSurround, SRS 3D stereo, and a switched‑capacitor external filter, all with soft‑switching circuitry and 1 µA‑class control bus.
The document lists absolute maximum ratings, operating voltage ranges, functional specifications, electrical characteristics, dimensional outlines, block diagrams, and important cautions for thermal design, pin orientation, and magnetic field exposure. Contact information for ROHM sales offices worldwide is also provided.
| Applied Voltage (SDA) | 7.0 V |
|---|---|
| Input Voltage (VIN) | VCC+0.3~GND-0.3 V |
| Power Dissipation (Pd) | 1190 µW |
| Operating Temperature (Topr) | -40 °C to +85 °C |
| Storage Temperature (Tastg) | -65 °C to +150 °C |
| Maximum Input Voltage (Visa) | 2.5 V |
| Maximum Output Voltage (Vom) | 2.5 V |
The maximum input voltage (Visa) is 2.5 V.
The device is rated for operation from –40 °C to +85 °C.
The absolute maximum power dissipation is 1190 µW.
The I²C bus operates with a control voltage of 3.3 V to 5.0 V.
