SH2002-DC90A printhead is a near-edge thermal printhead with 8 dots per inch, suitable for the high-speed continuous printing packaging printer market.
The SH2002-DC90A printhead features ROHM’s STEP FREE structure and an inclined printing surface that delivers high‑quality prints on cards, thick paper and non‑bendable media. It uses a hard conductive film to protect the heating element from electrostatic damage and is compatible with the SH3002‑DC90A mechanical specifications.
Technical data provided include print resolution, effective printing width, clock frequency, resistance values and electrical characteristics, along with application notes for barcode, card, ticket and compact printers used in high‑speed, 24‑hour production lines.
| Print resolution | 8 dots/mm |
|---|---|
| Effective printing width | 56 mm |
It prints at 8 dots per millimetre.
It is suitable for barcode printers, card printers, ticket printers and general‑purpose compact printers.
The effective printing width is 56 mm.
