Schroff 11396002 Power Supply User Manual

About this manual

This manual describes the Schroff 11396002 19" compatible AC/DC switched‑mode power supply. It includes the connector pin‑out, wiring diagrams, sense‑line operation, and instructions for series and parallel configurations. Technical data such as input voltage range, efficiency, output power options, and protection features are listed.

The document also covers safety information, warranty conditions, and environmental specifications. Guidance for proper installation, cooling, and handling of the unit is provided, along with details on current limiting, over‑voltage protection, and redundancy operation using the Current Share Bus (CSB). This manual is written in German.

What's inside

• Technical Data
• Input Parameters
• Output Parameters
• Connector Pin‑out
• Sense‑line Operation
• Parallel Operation
• Series Operation
• Safety and Protection Features
• Warranty

Specifications

Frequently asked questions

What over‑voltage protection does the power supply have?

It has a pre‑set over‑voltage protection that shuts the unit off and automatically resets when the fault clears.

How many power supplies can be connected in parallel for redundancy?

Up to twelve units can be paralleled, providing a maximum output of about 0.9 × Pmax.

What minimum load is required for redundancy operation?

A basic load of at least 0.1 × Pmax is required so that all units remain active.
