This manual provides instructions for using and managing the AXIS P3343-V Fixed Dome Network Camera, and is applicable to firmware 5.40 and later.
This manual is intended for administrators and users of the Axis P3343-V Fixed Dome Network Camera. It covers installation, network configuration, video and audio settings, security features, storage options, and troubleshooting.
Key sections include hardware overview, connector and LED descriptions, accessing the product via web browsers, live view controls, PTZ presets, advanced settings, and maintenance procedures such as firmware upgrades and factory reset.
| Power | Power over Ethernet IEEE 802.3af Class 2 |
|---|---|
| Dimensions | 96 mm x 148 mm x 148 mm |
| Weight | 0.7 kg |
| Processor | ARTPEC-3 |
| Memory | 128 MB RAM, 128 MB Flash |
| Audio input | 3.5 mm jack for mic in (max 80 mVpp) |
| Storage | SD/SDHC memory card slot (card not included) |
| Operating temperature | 0 °C to 50 °C |
| Network connector | RJ‑45 Ethernet connector with PoE |
Connect the camera to a PoE‑enabled RJ‑45 Ethernet switch using a shielded network cable; ensure the switch is properly grounded.
