VS9P is a low cost VCXO produced by RALTRON ELECTRONICS CORP., with a frequency range of 0.75 to 800 MHz, operating voltage of +3.3 VDC, and meeting LVPECL standards.
The VS9P series is a low‑cost voltage‑controlled crystal oscillator (VCXO) designed for high‑frequency applications such as InfiniBand, Fiber Channel, SATA, 10GbE, network processors, and SOHO routing. It features LVPECL output, a miniature lead‑less ceramic SMD package, and options for tri‑state output to aid testing.
The datasheet lists operating temperature from –40 °C to 485 °C, a supply voltage of 3.3 V (typical 4.6 VDC max), nominal frequencies from 0.75 MHz to 800 MHz, LVPECL output logic, and detailed phase‑noise and jitter performance. Mechanical dimensions, pin functions, and reflow profile specifications are also included.
| Operating temperature range | -40 °C to 485 °C |
|---|---|
| Supply voltage (Vcc) | +4.6 VDC (max) |
| Nominal frequency range | 0.75 MHz to 800 MHz |
| Output logic type | LVPECL |
| Random jitter (155.52 MHz) | 4 ps rms |
The device operates from –40 °C up to 485 °C.
It requires a supply voltage of 3.3 V nominal, with a maximum of +4.6 VDC.
The VCXO can be set to any frequency between 0.75 MHz and 800 MHz.
