MatchPort b/g is a very affordable embedded 802.11 b/g wireless networking module from Lantronix. It supports a variety of network interfaces, including wired and wireless, and has bulletproof security. It also comes with a full TCP/IP stack, Web server and Windows deployment software.
The MatchPort b/g is an embedded device server that adds 802.11 b/g wireless networking to any electronic device with a serial interface. It includes a dual‑processor design, a built‑in web server, and a full TCP/IP stack, allowing remote access and control over the Internet.
Key features include bullet‑proof security (AES‑CCMP, WPA‑PSK, TKIP, optional 256‑bit AES), a compact 45 mm × 45 mm form factor, up to 230 kbps data rate, and flexible power‑management. The module is FCC and CE certified and comes with development software such as DeviceInstaller and a web‑manager interface.
| Wireless Standards | IEEE 802.11b; 802.11g |
|---|---|
| Dimensions | 44.4 x 44.4 x 10.4 mm |
| Weight | 14 g |
| Maximum Output Power | 14 dBm + 2.0 dBm / -1.5 dBm |
| Maximum Receive Sensitivity | -21 dBm @ 1 Mbps |
| Range (indoor) | Up to 328 feet |
| Average Power Consumption (inactive) | 250 mW |
| Operating Temperature | -40 °C to 70 °C |
It supports IEEE 802.11b and IEEE 802.11g wireless standards.
The module measures 44.4 mm × 44.4 mm × 10.4 mm.
It offers IEEE 802.11i‑PSK, WPA‑PSK, TKIP and optional 256‑bit AES encryption.
