The DP83848C PHYTER® is a single-port 10/100 Mb/s Ethernet Physical Layer Transceiver with low power consumption and several intelligent power down states. It is suitable for a variety of applications, including high-end peripheral devices, industrial controls and factory automation.
The DP83848C PHYTER® is a robust, fully‑featured 10/100 Mbps Ethernet physical layer device. It offers low power consumption with several intelligent power‑down states and includes a 25 MHz clock output, allowing designs with minimal external components. The device interfaces to twisted‑pair media via an external transformer and supports MII, RMII, and SNI interfaces, ensuring flexibility for a wide range of applications.
Typical applications include high‑end peripheral devices, industrial controls, factory automation, and general embedded systems. The transceiver is offered in a compact 48‑pin LQFP package (7 mm × 7 mm) to save board space while providing features such as Auto‑MDIX, programmable LEDs, and built‑in self‑test capabilities.
| Clock Output | 25 MHz |
|---|---|
| Power Consumption | < 270 mW typical |
| Technology | Low‑power 3.3 V, 0.1814 µm CMOS |
| Package | 48‑pin LQFP (7 mm × 7 mm) |
| Supported Interfaces | MII, RMII, SNI, Auto‑MDIX |
The DP83848C provides a 25 MHz clock output.
It is supplied in a 48‑pin LQFP package measuring 7 mm × 7 mm.
Typical power consumption is less than 270 mW.
The device supports MII, RMII, and SNI interfaces, as well as Auto‑MDIX.
