This document is about the CS4923/4/5/6/7/8/9 multi-channel digital audio decoders, including product features, functions, application scenarios, etc.
The CS4923/4/5/6/7/8/9 family are multi‑channel digital audio decoders used in home A/V receivers, DVD players, set‑top boxes and similar equipment. The CS4929 variant is a stereo AAC and MPEG‑2 decoder, while the other members support Dolby Digital, DTS and MPEG‑2 multi‑channel decoding.
The datasheet lists electrical characteristics, pin assignments, timing diagrams, and recommended operating conditions. It also includes ordering information, typical connection diagrams, and details on host interfaces such as Intel, Motorola and SPI modes.
| Digital supply voltage (VD) | 3.13 V – 3.47 V (typ. 3.3 V) |
|---|---|
| Analog supply voltage (VA) | 3.13 V – 3.47 V (typ. 3.3 V) |
| Ambient operating temperature | 0 °C – 70 °C (typ.) |
| Digital input voltage range (VinD) | 0.3 V – 5.5 V |
| Digital power supply current | 225 mA – 435 mA |
| Reset minimum pulse width | 100 ns |
| CMPCLK period (compressed data clock) | 37 ns |
| CLKIN period (internal DSP clock mode) | 20 ns – 3800 ns |
| Maximum input current per pin | 10 mA |
The digital supply voltage (VD) operates from 3.13 V to 3.47 V, with a typical value of 3.3 V.
The device is specified for an ambient temperature between 0 °C and 70 °C.
Each pin (except supply pins) can handle up to 10 mA of input current.
