The AD9200 is a monolithic, single supply, 10-bit, 20 MSPS analog-to-digital converter with an on-chip sample-and-hold amplifier and voltage reference...
The AD9200 is a monolithic, single‑supply, 10‑bit, 20 MSPS analog‑to‑digital converter with an on‑chip sample‑and‑hold amplifier and voltage reference. It supports single‑ended or differential inputs, multiple reference configurations, and includes features such as three‑state outputs, an out‑of‑range indicator, and built‑in clamp functions.
The datasheet provides detailed specifications, pin configurations, operational modes, grounding and layout guidelines, and ordering information for the 28‑lead SSOP and 48‑lead LQFP packages. It also includes performance graphs for dynamic range, distortion, and power consumption.
| Resolution | 10 bits |
|---|---|
| Conversion Rate | 20 MHz |
| Power‑down (sleep) Consumption | 4 mW |
| Supply Voltage Range | 2.7 V to 5.5 V |
| Input Voltage Span | 0.5 V to 2.5 V |
| Differential Nonlinearity (DNL) | -0.5 to 1 LSB |
| Integral Nonlinearity (INL) | -0.75 to 2 LSB |
| Package Options | 28‑lead SSOP, 48‑lead LQFP |
| Pin Compatibility | Pin compatible with AD876 |
It is offered in a 28‑lead SSOP package and a 48‑lead LQFP package.
Yes, the AD9200 is pin compatible with the AD876.
The input voltage can span from 0.5 V to 2.5 V (2 V input span).
