The AD9480 is an 8-bit, 250 MSPS, 3.3 V analog-to-digital converter (ADC) optimized for high speed and low power consumption. Small in size and easy to integrate, it is suitable for a variety of applications, such as digital oscilloscopes, instrumentation and measurement, communications, point-to-point radios, and predistortion loops.
The AD9480 is an 8‑bit, monolithic analog‑to‑digital converter optimized for high speed and low power consumption. It operates from a single 3.3 V supply, includes an internal reference and a track‑and‑hold circuit, and provides LVDS differential outputs compatible with ANSI‑644.
Key specifications include a maximum conversion rate of 250 MSPS, power dissipation of 590 mW (down to 15 mW in power‑down mode), a 1 V p‑p analog input range, and an internal 1.0 V reference. The device is supplied in a 44‑lead TQFP package and is suited for digital oscilloscopes, instrumentation, communications and point‑to‑point radios.
| Resolution | 8 Bits |
|---|---|
| Output Interface | LVDS (ANSI‑644) |
The device outputs LVDS differential signals compliant with ANSI‑644.
