AD9637 is an 8-channel, 12-bit, 40/80 MSPS, serial LVDS, 1.8 V analog-to-digital converter from AD.
The AD9637 is an octal, 12‑bit analog‑to‑digital converter offering up to 80 MSPS conversion rate. It operates from a single 1.8 V supply and provides LVDS, CMOS, or LVPECL serial outputs, making it suitable for compact, low‑power applications.
The device includes programmable features such as digital test pattern generation, individual channel power‑down, and flexible clock and data alignment. It is supplied in a RoHS‑compliant 64‑lead LFCSP package and is rated for an ambient temperature range of –40 °C to +85 °C.
| Resolution | 12 bit |
|---|---|
| Maximum Sample Rate | 80 MSPS |
| Supply Voltage (AVDD/DRVDD) | 1.8 V |
| Input Voltage Range | 2 V p‑p differential |
| Power per Channel (80 MSPS) | 60 mW |
| Signal‑to‑Noise Ratio | 71.5 dBFS |
| Operating Temperature Range | –40 °C to +85 °C |
The AD9637 operates from a single 1.8 V supply for both AVDD and DRVDD.
It can sample at up to 80 MSPS.
Each channel uses about 60 mW at 80 MSPS.
The device accepts a 2 V peak‑to‑peak differential input.
