This manual provides step‑by‑step instructions for operating the Nikon N4004S 35 mm SLR camera. It covers everything from mounting lenses and installing batteries to loading film, selecting exposure modes, and using the built‑in TTL flash.
Additional sections describe autofocus operation, manual focus techniques, self‑timer use, camera care tips, and detailed specifications such as shutter speed range, film speed compatibility, dimensions, and weight.
| Camera type | 35 mm single‑lens reflex with built‑in TTL flash |
|---|---|
| Lens mount | Nikon bayonet mount AF Nikkor lenses |
| Focusing modes | Autofocus, manual focus with focusing confirmation |
| Film speed range | ISO 25 to 5000 for DX‑coded film |
| Dimensions (W × H × D) | 154 mm × 102 mm × 65.5 mm |
| Weight (body only) | ≈650 g |
| Battery type | Four AA‑type batteries (Alkaline, NiCd or Zinc‑carbon) |
The camera uses four AA‑type batteries.
It supports ISO 25 to 5000 for DX‑coded film; non‑DX film defaults to ISO 100.
Press the shutter release button lightly; the exposure indicator LED will light up or blink if power is sufficient.
