This is the instruction manual for a Nikon Nikomat ELW camera.
This manual introduces the Nikon Nikomat ELW 35 mm SLR camera, covering its automatic exposure system, built‑in TTL meter, and compatible accessories such as the Auto Winder AW‑1. It explains basic operations, lens mounting, exposure control, and safety locks to help users achieve reliable results.
Additional sections detail specifications, battery care, lens hood usage, and comprehensive camera‑care recommendations to maintain performance in various environments.
| Camera type | 35 mm Single Lens Reflex |
|---|---|
| Picture area | 24 mm × 36 mm |
| Lens mount | Nikon F bayonet |
| Viewfinder type | Eye‑level pentaprism |
| Viewfinder frame coverage | ≈ 92 % of final picture area |
| Shutter type | Electromagnetic‑controlled focal‑plane, vertical movement |
| Shutter speed range (manual) | 1/1000 sec to 4 sec (plus B) |
| Exposure meter | TTL CdS, center‑weighted, full‑aperture |
| ASA range | 25 – 1600 |
If the exposure‑meter battery is exhausted, the shutter will still operate mechanically at 1/90 sec.
The viewfinder covers approximately 92 % of the final picture area.
