CK-components is a supplier of switches and connectors. This PDF file is a product selection guide for the company's 7000 series miniature toggle switches. It introduces the features and characteristics of these products, including multi-pole and multi-position, wide range of actuators and termination options, epoxy terminal seal compatible with bottom wash cleaning, RoHS complaint models available.
This guide details the 7000 Series miniature toggle switches, covering a wide range of pole/throw configurations, actuator styles, and termination options. It includes electrical ratings, mechanical dimensions, and material specifications for each model.
The document also lists mounting options (panel, rear, vertical, right‑angle), bushing types, and RoHS‑compliant variants, plus special military‑grade MIL‑S‑83731 switches. Ordering information and part numbers are provided for quick selection.
| Contact rating (B) | 0.4 VA @ 20 V AC/DC |
|---|---|
| Electrical life (7X01/UX1 models) | 100,000 cycles |
| Contact resistance | < 10 mΩ typical |
| Dielectric strength | ≥ 1000 V rms |
| Operating temperature range | ‑30 °C to 85 °C |
Yes, models supplied with contact materials P, SR, Q, B or G are RoHS compliant.
Yes, the guide includes MIL‑S‑83731 qualified toggle switches for aerospace and military applications.
