The ABL heat sink series LS80, LS85 and LS90 are pressed‑aluminium components designed for efficient thermal dissipation. Each model provides a thermal resistance of approximately 0.7 °C/W and offers two mounting holes for secure attachment.
Mounting can be performed using screws or a dedicated clip (see Clip 4.5). Contact details for ABL Aluminium Components Ltd are provided for ordering and technical support.
| LS80 Thermal resistance | 0.7 °C/W |
|---|---|
| LS85 Thermal resistance | 0.7 °C/W |
| LS90 Thermal resistance | 0.7 °C/W |
| LS80 Mounting holes | 2 holes @ 5.08 mm |
| LS85 Mounting holes | 2 holes B40 |
| LS90 Mounting holes | 2 holes @ 4.08 mm |
The device may be fixed with a screw or a clip (see Clip 4.5).
The LS85 heat sink has a thermal resistance of about 0.7 °C/W.
