The MAX4599 is a single-channel low-voltage switch produced by Maxim. It operates at a supply voltage of +2.0V to +5.5V, has a switch resistance of 60 ohms, and a switching time of 30ns. It comes in SC70, µDFN, and SOT23 packages.
The MAX4599 is a low‑voltage, single‑supply SPDT analog switch that operates from +2.0 V to +5.5 V. It is offered in 6‑pin SC70, UDFN, and SOT23 packages and is suitable for battery‑operated equipment, audio/video routing, cellular phones, data‑acquisition systems, and other low‑voltage applications.
Key features include 60 mΩ typical on‑resistance at +5 V, fast switching (ton = 30 ns, toff = 25 ns), 5 pC maximum charge injection, 200 MHz -3 dB bandwidth, and low leakage current (0.5 nA at +25 °C). The device provides break‑before‑make operation and TTL/CMOS‑compatible logic levels.
| Supply Voltage Range | +2.0 V to +5.5 V |
|---|---|
| On‑Resistance (RON) at +5 V | 60 mΩ max |
| Ron Matching Between Channels | 19 mΩ max (0.22 Ω typ) |
| Ron Flatness | 4 mΩ max (2.5 mΩ typ) |
| Switching Time (ton) | 30 ns max |
| Switching Time (toff) | 25 ns max |
| Charge Injection | 5 pC max |
| Bandwidth (-3 dB) | 200 MHz |
| Leakage Current | 0.5 nA at +25 °C |
The MAX4599 operates from a single supply of +2.0 V to +5.5 V.
At +5 V the device has a maximum on‑resistance of 60 mΩ.
The MAX4599 guarantees a maximum charge injection of 5 pC.
