The MAX4754/MAX4754A/MAX4755/MAX4756/MAX4756A series low on-resistance, analog switches operate from a single +1.8V to +5.5V supply. They are configured to route either audio or data signals.
The MAX4754, MAX4754A, MAX4755, MAX4756 and MAX4756A are low‑on‑resistance analog switches that operate from a single +1.8 V to +5.5 V supply. They are offered in 16‑pin TQFN and 16‑bump UCSP (2 mm × 2 mm) packages and are intended for audio‑signal routing and data‑signal switching in mobile devices, notebooks and other portable electronics.
The datasheet provides absolute maximum ratings, detailed electrical characteristics, typical operating curves, pin descriptions, timing diagrams and package drawings. It also includes ordering information and revision history for the product family.
| Supply Voltage Range | 1.8 V to 5.5 V |
|---|---|
| Package Options | 16‑pin TQFN, 16‑bump UCSP (2 mm × 2 mm) |
The devices operate from a single supply voltage of 1.8 V up to 5.5 V.
