The MAX2016 is a dual logarithmic detector/controller designed for measuring and comparing power, gain/loss, and voltage standing-wave ratio (VSWR) of two incoming RF signals.
The MAX2016 is a fully integrated dual‑channel logarithmic detector and controller that measures and compares RF power, gain/loss, and VSWR of two incoming signals. It operates from a single +2.7 V to +5.25 V supply and works over an extended temperature range of –40 °C to +85 °C, providing an 80 dB dynamic range and a 0.5 V to 1.8 V output voltage swing.
The device supports RF frequencies from low‑frequency up to 2.5 GHz, offers a window detector via on‑chip comparators, and is available in a space‑saving 5 mm × 5 mm, 28‑pin thin QFN package. Typical applications include dual‑channel power measurements, AGC control, VSWR monitoring, and remote system diagnostics for base stations, radar, and other RF systems. This manual is written in Chinese.
| Supply Voltage | 2.7 V to 5.25 V |
|---|---|
| Operating Temperature Range | –40 °C to +85 °C |
| Dynamic Range | 80 dB |
| Package | 5 mm × 5 mm, 28‑pin thin QFN |
The MAX2016 operates from a single supply voltage of +2.7 V to +5.25 V.
The MAX2016 provides an 80 dB dynamic range.
It is available in a 5 mm × 5 mm, 28‑pin thin QFN package.
