ADP362x/ADP363x is a product with high speed, dual channels, and 4A MOSFET drivers. It features an industry-standard-compatible pinout, high current drive capability, precise threshold shutdown comparator, UVLO with hysteresis, overtemperature warning signal, and overtemperature shutdown.
The ADP3623/ADP3624/ADP3625/ADP3633/ADP3634/ADP3635 family provides high‑current, dual‑channel drivers capable of driving two independent N‑channel power MOSFETs. The devices feature industry‑standard pinouts, 3.3 V‑compatible inputs, fast 10 ns rise/fall times, and built‑in temperature sensing with warning and shutdown thresholds.
Key applications include AC‑DC and DC‑DC switch‑mode power supplies, synchronous rectification, and motor‑drive circuits. The datasheet details electrical specifications, absolute maximum ratings, pin configurations, typical performance curves, PCB layout guidelines, and ordering information for the various package options.
| Typical Rise/Fall Time | 10 ns (2.2 nF load) |
|---|
Typical rise and fall times are about 10 ns when driving a 2.2 nF load.
It can drive two independent N‑channel power MOSFETs, one per channel.
