The LT ®1632/LT1633 are dual/quad, rail-to-rail input and output op amps with a 45MHz gain-bandwidth product and a 45V/µs slew rate. The LT1632/LT1633 have excellent DC precision over the full range of operation. Input offset voltage is typically less than 400µV and the minimum open-loop gain of 0.8 million into a 10k load virtually eliminates all gain error. Common mode rejection is typically 83dB over the full rail- to-rail input range when on a single 5V supply for excellent noninverting performance. The LT1632/LT1633 maintain their performance for sup- plies from 2.7V to 36V and are specified at 3V, 5V and ±15V supplies. The inputs can be driven beyond the supplies without damage or phase reversal of the output. The output delivers load currents in excess of 35mA.
The LT1632 and LT1633 are dual (LT1632) or quad (LT1633) precision operational amplifiers featuring rail‑to‑rail input and output, a 45 MHz gain‑bandwidth product, and a 45 V/µs slew rate. They operate from a wide supply range of 2.7 V to +15 V and can source up to 35 mA of output current, making them suitable for low‑power and battery‑powered applications.
Typical applications include active filters, rail‑to‑rail buffer amplifiers, driving A/D converters, and low‑voltage signal processing. The devices maintain high DC accuracy across temperature, with input offset voltages as low as 1350 µV and common‑mode rejection ratios around 83 dB.
| Gain‑Bandwidth Product | 45 MHz |
|---|---|
| Slew Rate | 45 V/µs |
| Supply Voltage Range | 2.7 V to +15 V |
| Output Drive Current | 35 mA (minimum) |
| Input Offset Voltage (max) | 1350 µV |
The gain‑bandwidth product is 45 MHz.
They have a typical slew rate of 45 V/µs.
They operate from 2.7 V up to +15 V.
Each amplifier can source at least 35 mA of output current.
