This document introduces the features and characteristics of the LT6552 differential amplifier, including differential to single-ended conversion, video line driver, automotive displays, RGB amplifiers, coaxial cable drivers and low voltage high speed signal processing.
The LT6552 is a video difference amplifier optimized for low‑voltage single‑supply operation. It can be used in differential or single‑ended configurations and supports a wide supply range of 3 V to 12.6 V, delivering rail‑to‑rail output swings and up to 70 mA output drive.
Key electrical characteristics include a 75 MHz -3 dB bandwidth at 3.3 V, 600 V/µs slew rate, >60 dB CMRR at 10 MHz, and operation over –40 °C to 85 °C. The device is offered in 8‑lead SO and tiny 3 mm × 3 mm × 0.8 mm DFN packages, with detailed absolute maximum ratings and typical performance graphs provided.
| Supply Voltage Range | 3 V to 12.6 V |
|---|---|
| Operating Temperature Range | –40 °C to 85 °C |
| Bandwidth (3.3 V supply) | 75 MHz (‑3 dB) |
| Slew Rate | 600 V/µs |
| Output Drive Capability | +70 mA |
| CMRR (10 MHz) | >60 dB |
| Shutdown Power Consumption | ≤300 µA |
| Package Types | 8‑Lead Plastic SO, 3 mm × 3 mm × 0.8 mm DFN |
The LT6552 operates from 3 V up to 12.6 V.
It provides a 75 MHz –3 dB bandwidth when powered at 3.3 V.
The device can source up to +70 mA of output current.
The common‑mode rejection ratio exceeds 60 dB at 10 MHz.
