This document is the specification for BTHQ 21603VSS-06, which introduces the features and characteristics of the product, including mechanical dimensions, interface signals, absolute maximum ratings, environmental conditions, electrical specifications, typical electrical characteristics, timing specifications, voltage Vs and voltage V0 timing diagram, correspondence between character codes and character patterns.
The BTHQ 21603V-STF-LV-LED Y.G. is a 16‑character (5×8 dots) ×2‑line STN positive yellow transflective dot‑matrix LCD module with a 6 o’clock viewing angle. It uses a NOVATEK NT3881DH‑01/AI controller and a Samsung KS0065B‑PCC driver, and features a 16‑pin SMD FULLCONN connector for power and data.
Key specifications include outline dimensions of 53 mm × 20 mm × 8 mm, an effective viewing area of 36 mm × 10 mm, and a typical operating supply voltage of 5 V (logic) with a LED forward voltage of 3.9‑4.1 V. The module operates from 0 °C to +50 °C (storage –10 °C to +60 °C) and draws up to 2 mA in character mode.
| Effective viewing area | 36.0 x 10.0 mm |
|---|---|
| Weight | Approx. 11.0 grams |
| Logic supply voltage (VDD‑VSS) | 4.75 – 5.25 V |
| LED forward voltage | 3.9 – 4.1 V |
| Display characters | 16 characters x 2 lines (5×8 dots) |
| Connector type | 16‑pin SMD FULLCONN (CON‑16X1‑35) |
The module operates from 0 °C to +50 °C, with storage limits of –10 °C to +60 °C.
It uses a 16‑pin SMD "FULLCONN" connector (part number CON‑16X1‑35).
The LCD can display 16 characters per line, with 5×8 dot characters, over 2 lines.
The yellow‑green backlight LED has a forward voltage of 3.9 V to 4.1 V at 20 mA.
