The SaRonix STT Series crystal clock oscillators provide precise rise and fall times for driving TTL loads and micro‑processors. They feature a tri‑state output, optional reverse‑logic input, and high‑drive capability up to 50 mA sink/source.
The devices are offered in full‑size (14‑pin DIP compatible) and half‑size (8‑pin DIP compatible) packages, with a wide frequency range from 250 kHz to 135 MHz and stability options of ±25, ±50, or ±100 ppm. Electrical specifications include an operating supply of +8 VDC ±10% and various current limits depending on frequency.
| Frequency Range | 250 kHz to 135 MHz |
|---|---|
| Frequency Stability | +25, +50, +100 ppm |
| Operating Temperature | OPC to +70 °C |
| Supply Voltage (operating) | +8 VDC ±10% |
| Supply Current (typical, ≤60 MHz) | 20 mA typical, 30 mA max @ 25 °C |
| Package Types | Full‑size (14‑pin DIP) and Half‑size (8‑pin DIP) |
The STT Series covers frequencies from 250 kHz up to 135 MHz.
The device can sink and source up to 50 mA of TTL load current.
Both full‑size (14‑pin DIP compatible) and half‑size (8‑pin DIP compatible) packages are offered.
