This document is about BTHQ 128064AVC-STF-06-LED02YG-COG specification, including mechanical, electrical, environmental parameters.
The BTHQ 128064AVC-STF-06-LED02YG-COG is a 128 × 64 dot STN yellow‑positive transflective LCD module with a 6 o’clock viewing direction and a yellow‑green LED02 backlight. It uses a UC1606 (COG) controller‑driver and operates from a +3 V logic supply.
The document provides mechanical dimensions, pin‑out, absolute maximum ratings, electrical specifications and timing characteristics for both parallel and serial interfaces, as well as environmental limits for temperature and humidity.
| Display format | 128 x 64 dots |
|---|---|
| Logic supply voltage (VDD1‑VSS) | -0.3 V to +5.5 V |
| LCD generator supply voltage (VDD2‑VSS) | -0.3 V to +5.5 V |
| Analog circuit supply voltage (VDD3‑VSS) | -0.3 V to +5.5 V |
| Operating temperature range | 0 °C to +50 °C |
| Backlight type | Yellow‑Green LED02 |
The module has a resolution of 128 × 64 dots.
All supply voltages (VDD1‑VSS, VDD2‑VSS, VDD3‑VSS) may range from –0.3 V to +5.5 V.
The viewing direction is specified as 6 o’clock.
The module is rated for ambient temperatures from 0 °C to +50 °C.
