The TLM‑T120FTHA‑01 is a 1.2" transflective LTPS display module with a 65K color depth. It offers a resolution of 128 × RGB × 160 dots and a viewing angle of 6 o'clock. The module operates from –20 °C to +70 °C and can be stored between –30 °C and +80 °C.
Key electrical characteristics include a logic voltage of 27 V, a backlight luminance minimum of 2500 cd/m², and a driving voltage of 33 V for the backlight. Pin assignments and detailed dimensions are provided for integration into host systems.
| Display Type | 65K 1.2" TRANSFLECTIVE LTPS |
|---|---|
| Display Resolution | 128 x RGB x 160 DOTS |
| Viewing Angle | 6 O'CLOCK |
| Logic Voltage | 27V |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -30°C to +80°C |
| Backlight Luminance (minimum) | 2500 cd/m² |
| Backlight Driving Voltage | 33V |
The module operates from –20 °C to +70 °C.
The required logic voltage is 27 V.
The backlight luminance minimum is 2500 cd/m².
It uses a 65K 1.2‑inch transflective LTPS display.
