G62 CMOS is a low cost VCXO, with frequency range 0.625MHz to 50.0MHz, CMOS/TTL output, supply voltage 5.0V or 3.3Vdc, integrated phase jitter 1ps typical value
The G62 VCXO from EuroQuartz is packaged in a compact 11.4 mm × 9.6 mm × 2.5 mm 6‑pad SMD case. It uses fundamental‑mode crystal oscillators and is intended for applications such as PLLs, set‑top boxes, MPEG, audio/video modulation, video‑game consoles and HDTV.
Key specifications include a frequency range of 0.625 MHz to 50 MHz, supply options of 3.3 VDC or 5.0 VDC (±5 %), TTL/HCMOS output, integrated phase jitter of up to 1 ps, period jitter RMS of 2 ps typical, start‑up time up to 10 ms (5 ms typical), and rise/fall times of about 0.7 ns with a 15 pF load. The device operates from –50 °C to +100 °C and meets RoHS requirements.
| Frequency Range | 0.625 MHz to 50 MHz |
|---|---|
| Supply Voltage | +3.3 VDC ±5 % or +5.0 VDC ±5 % |
| Output Logic | TTL/HCMOS |
| Period Jitter RMS | 2.0 ps typical |
| Start‑up Time | 10 ms max, 5 ms typical |
| Rise/Fall Times | 0.7 ns typical (15 pF load) |
| Operating Temperature Range | -50 °C to +100 °C |
It covers 0.625 MHz to 50 MHz.
It can be powered from 3.3 VDC or 5.0 VDC, each with a ±5 % tolerance.
Start‑up time is up to 10 ms maximum, typically about 5 ms.
