This manual provides instructions and precautions for operating the YSP-CU2200 + NS-SWP600 Digital Sound Projector™, including installation location, ventilation requirements, and usage environment. It also reminds users to avoid placing other objects on the device and to prevent the device from being exposed to liquid dripping or splashing.
The YSP-2200 is a digital sound projector designed for home theater use, offering surround sound formats such as Dolby TrueHD, DTS‑HD, and Multi‑channel PCM. This manual covers everything from unpacking and supplied accessories to connecting the unit to TVs, Blu‑ray players, game consoles, and iPods.
Installation guidelines include required clearances, power‑cable grounding, and remote‑control preparation. Detailed sections explain front‑panel controls, rear‑panel connections, audio‑ and video‑input options, and advanced features like IntelliBeam and UniVolume. Troubleshooting tips and an appendix with specifications complete the guide.
| Top clearance | 5 cm (2 in) |
|---|---|
| Rear clearance | 5 cm (2 in) |
| Side clearance | 1 em (13/32 in) |
Leave at least 5 cm (2 in) of space on the top and rear, and 1 em (13/32 in) on each side of the unit.
The power‑supply cable must be plugged into a mains outlet that has a protective earthing connection.
