This document provides the dimensional data for Pilot SIMPLEX 06B1 bored sprockets. It lists the pitch, outer diameter, hub length, plate thickness and other key measurements for each size option.
Key specifications such as the 3/5 pitch, a 70 mm outside diameter, a 30 mm hub diameter, and precise bore tolerances (+0.28 mm) are included, allowing engineers to select the correct sprocket for their application.
| Length Through Bore Tolerance | +0.25 mm |
|---|
