This document provides specifications for Samsung Electro-Mechanics' LED lighting products, including product features, absolute maximum ratings, chromaticity diagram, typical characteristic graphs, dimensions and outlines, reliability test items and conditions, solder conditions, taping dimensions, label structure, lot number, reel packing structure, aluminum vinyl bag, precautions for use, hazard substance analysis, and revision history.
The SLSNNWW815TS is a warm‑white LED package designed for indoor and outdoor display applications. It features a 5.2 × 6.0 × 1.3 mm lead‑frame, a 120° beam angle, and a GaN/Al₂O₃ LED chip.
The datasheet lists absolute maximum ratings such as a 30 mA forward current, 100 mA peak pulsed current, and operating temperatures from –30 °C to 85 °C. It also details reliability test conditions, soldering limits, tape dimensions, and packaging information for mass production.
| Forward Current (per chip) | 30 mA |
|---|---|
| Peak Pulsed Forward Current (per chip) | 100 mA (Duty 1/10, 10 ms) |
| Reverse Current | 85 mA |
| Operating Temperature Range | -30 °C ~ 85 °C |
| Storage Temperature Range | -40 °C ~ 100 °C |
| Forward Voltage (typ) | 2.9 V ~ 3.6 V |
| Luminous Intensity (typ) | 4 cd ~ 6.8 cd |
| Package Dimensions | 5.2 × 6.0 × 1.3 mm |
| Beam Angle | 120° |
The maximum forward current per chip is 30 mA.
It can operate from –30 °C up to 85 °C.
