This document is an instruction manual for the Nikon Motor Drive MD-12, which describes the components and operation of the product, including single-frame shooting, continuous shooting, and film rewinding.
This manual explains how to load the eight AA batteries, attach the MD-12 motor drive to Nikon FM or FE cameras, and operate the device in single‑frame or continuous shooting modes. It also describes the functions of the power switch, pilot lamp, and remote control accessories.
Additional sections cover troubleshooting common issues such as motor jams, battery performance tips, and detailed specifications including shooting speed, shutter speed ranges, dimensions, and power requirements.
| Maximum shooting speed | 3.5 frames per second (approx.) |
|---|---|
| Usable shutter speeds (single‑frame, FM) | 1 – 1/1000 sec. |
| Usable shutter speeds (single‑frame, FE) | 8 – 1/1000 sec., Auto, M90 |
| Usable shutter speeds (continuous, FM) | 1/2 – 1/1000 sec. |
| Power source | Eight 1.5 V AA batteries |
| Weight (without batteries) | ≈ 410 g |
| Dimensions (including grip) | ≈ 144 × 68.5 × 109.5 mm |
| Pilot lamp | LED, lights up in operation |
