About this manual

This guide covers safety precautions, installation, and basic operation of the Nokia 22 PBX connectivity terminal. It includes instructions for mounting the GSM terminal, connecting power and a telephone, installing the SIM card, and entering the PIN code.

The manual also lists accessories, troubleshooting tips, technical specifications, and care and maintenance recommendations to ensure reliable performance and compliance with regulatory requirements.

What's inside

For Your Safety
Introduction
Getting Started
Light Indicators
Tone Indicators
Nokia 22 Accessories
Troubleshooting
Technical Specifications
Important Safety Information
Care and Maintenance

Specifications

PBX interfaces	2
RS-232 data connector	present
Power supply connector	present

Frequently asked questions

How do I install the SIM card?

Insert the SIM card with the golden contact area facing downwards, taking care not to damage the card.

Can I connect the power supply before installing the SIM card?

No – you must install the SIM card and mount the GSM terminal before connecting the power supply to an AC outlet.
